Active production – BOM‑ready fit for 40 mm sense zones
The XS8C4A4PCP20: Rectangular plastic body measures 40 mm W × 40 mm D × 117 mm H, with a top‑sensing face and 5‑position turret head for adjusting the sensing direction. Sensing distance is 40 mm, unshielded, requiring non‑flush mounting clearance. Output is PNP, selectable NO or NC. Operating voltage 12 to 48 VDC, switching frequency 200 Hz, maximum load current 200 mA. Rated IP65, IP67, and IP69K — suitable for high‑pressure washdown environments. Approvals include UL, CSA, CE.
Mounting and environmental fit
Non‑flush (unshielded) installation requires free space around the face — standard practice for 40 mm unshielded sensors. The 5‑position turret head lets you orient the sensing face top, front, or at intermediate angles, simplifying alignment in tight enclosures. Screw terminals accept ferrule‑crimped conductors (typical strip length 8 mm). The IP69K rating allows steam‑clean and high‑pressure washdown cycles; plastic body resists corrosion in wet environments. Switching frequency is 200 Hz.
