Telemecanique XS9 Series, Inductive Proximity Sensor, XS9C4A2A1G13, 25 mm, 0-10V DC, IP65/IP67/IP69K.
| Parameter | Value |
|---|---|
| Series | XS9 |
| Parameter | Value |
|---|---|
| Sensing distance, max. (alt.) | 25 mm |
| Sensing method | Inductive |
| Sensing-face shielding | Unshielded |
| Parameter | Value |
|---|---|
| Supply voltage | Not Rated ; 24V DC |
| AC supply voltage rating | Not Rated |
| DC supply voltage rating | 24V DC |
| Number of wires | 3 |
| Electrical connection | Bare Wire |
| Electrical installation type | Screw Clamp Terminal |
| Parameter | Value |
|---|---|
| Output circuit type | Analog |
| Includes indicator lights | Indicator Lights Included |
| Output circuit | Analog |
| Parameter | Value |
|---|---|
| Body style | Rectangular |
| Overall height | 117 mm |
| Body material | PBT |
| Parameter | Value |
|---|---|
| Operating temperature, max. (alt.) | 158 °F |
| Operating temperature, min. (alt.) | -13 °F |
| IP rating | IP65; IP67; IP69K |
| Parameter | Value |
|---|---|
| Standards / certifications | CE; CSA; RoHS; UL Listed |
Rectangular inductive proximity sensor XS9C4A2A1G13 outputs analog 0 to 10 V DC, sensing to 25 mm unshielded. IP69K PBT housing for high-pressure washdown.
Body dimensions 40 mm wide by 40 mm deep by 117 mm tall. Bare wire termination via screw clamp terminals; 3-wire interface for supply, output, and common. Include the indicator light for local status. Unshielded sensing face gives 25 mm range without need for shielded mounting surface.
It carries IP65, IP67, and IP69K ratings, making it suitable for dust ingress, temporary immersion, and high-pressure, high-temperature washdown.
It is CE, CSA, RoHS, and UL listed. Documentation for these certifications can be provided upon request.
It is part of the Telemecanique XS9 series of inductive proximity sensors.
