The Schneider XSAN01122 is an inductive proximity sensor from the OsiSense XS series, with a 10 mm nominal sensing distance and a 1 NC discrete output, rated for 12-24 V DC supply. Rated IP67 per IEC 60529 and CE marked, it is designed for flush mounting in M30 threaded ports, typical for rotation monitoring or presence detection in industrial control panels.
Mounting and Environmental Fit
Flush mountable body with M30 x 1.5 thread, 81 mm overall length (3.19 in), and 30 mm height (1.18 in). The cable exits axially; allow 57 mm threaded engagement into the mounting surface. Operating temperature -25 to 70 °C, IP67 seal against dust and water jets. The single red LED confirms output state, aids commissioning.
