Schneider Electric XSAN01122EX — Proximity Sensors

Telemecanique XSAN01122EX Inductive Proximity Sensor, M8, Na

MPNXSAN01122EX

Telemecanique OsiSense XS XSAN01122EX inductive proximity sensor, M8 x 1, Namur, ATEX dust, 1.5 mm, 2-wire DC.

$76.20 – $112.00Ref. price · indicative, final on quote
Schneider Electric XSAN01122EX datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

XSAN01122EX — Output
ParameterValue
Output circuit typeDC
Switching frequency<= 1.5 kHz
XSAN01122EX — Electrical
ParameterValue
Electrical connectionCable
XSAN01122EX — Mechanical
ParameterValue
Size26.5 mm
Length1.04 in (26.5 mm)
Cable length6.56 ft (2 m)
XSAN01122EX — Approvals
ParameterValue
Standards / certificationsEN/IEC 60079-0 , EN/IEC 60079-11

Product details

The XSAN01122EX: M8 x 1 cylindrical inductive sensor from the OsiSense XS ATEX D range, with a 2-wire DC Namur output. Rated for ATEX dust zone 20 (II 1 D Ex ia IIIC T85°C Da), IP66/67. Nominal sensing distance 1.5 mm, switching frequency up to 1.5 kHz. Supply 7–12 V DC; residual current ≤3 mA in open state.

Cylindrical M8 body with frontal detection, 26.5 mm threaded length. Fixed 2 m cable, 2 x 0.11 mm², PvR insulation; two-wire DC Namur circuit, observe polarity, load ≤1 mA switching capacity.

Genuine Telemecanique sensor ships with full ATEX documentation. This XSAN01122EX is a dedicated Namur, M8, frontal face for dust zone 20, distinct from XS9E11RPBL01M12 or XS608B1DBL2.

MPN
XSAN01122EX
