What It Is and What It Does
This XSAV11373TF is an M30 tubular inductive proximity sensor from Telemecanique's XS range — the one you reach for when you need reliable 10mm metal detection in automation lines. It runs on 12 to 48 VDC and delivers a 200 mA output, strong enough to drive a relay coil or a PLC input without an amplifier. The speed detection up to 150 cycles per minute makes it a natural fit for monitoring rotating shafts or counting parts on a conveyor.
Mounting & Integration
Standard M30 threaded barrel — mounts in any bracket or tapped hole designed for that size. The 200 mA rated output is current-sourcing; make sure your input card matches the polarity (no explicit PNP/NPN in the part markings, so confirm your wiring). The wide 12-48 VDC supply range gives you headroom to use it on existing 24V or 48V panels without a dedicated converter.
