Schneider Electric XU2M18AP20D — Photoelectric Sensors

Schneider XU2M18AP20D Photoelectric Sensor Set, 70 m Through-Beam

MPNXU2M18AP20D

Schneider XU2M18AP20D Photoelectric Sensors.

$72.39Ref. price · indicative, final on quote
Schneider Electric XU2M18AP20D datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

XU2M18AP20D — Identification
ParameterValue
SeriesXU2
XU2M18AP20D — Sensing
ParameterValue
Sensing methodThrough-Beam
Response time15 msec
XU2M18AP20D — Electrical
ParameterValue
Supply voltage12-24V DC
XU2M18AP20D — Environmental
ParameterValue
IP ratingIP67
Operating temperature, max.131 °F
XU2M18AP20D — Mechanical
ParameterValue
Body materialMetal
XU2M18AP20D — Approvals
ParameterValue
Standards / approvalsCE; CSA; UL Listed

Product details

Overview

The XU2M18AP20D is a Schneider XU2 through-beam photoelectric sensor set — transmitter and receiver in one order code — rated for a 70 m sensing distance on a 12-24V DC supply with a PNP output. Housed in an M18 threaded metal barrel sealed to IP67, it switches at 30 Hz with a 15 msec response time and terminates in a 4-pin M12 connector.

Against the XUB1APANM12 retroreflective sensor, the XU2M18AP20D delivers a 70 m through-beam range versus 5.5 m, but switches at 30 Hz versus 500 Hz — pick the XU2 for long-axis alignment gates and the XUB for high-speed retroreflective detection on conveyors.

The XU2M18AP20D is a current Schneider catalogue sensor; lead time is typically short, and an RFQ confirms availability for the exact build variant.
