Schneider Electric ZB4BW9337 — Emergency Stop Pushbuttons

Schneider Electric ZB4BW9337

MPNZB4BW9337
Obsolete

green flush illuminated pushbutton head Ø22 spring return for integral LED

Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

ZB4BW9337 — Identification
ParameterValue
Product typeHead for illuminated push-button
Product rangeHarmony XB4
Device short nameZB4
Operator profileGreen flush, unmarked
ZB4BW9337 — Function & Operation
ParameterValue
Signaling head shapeRound
ZB4BW9337 — Switching & Contacts
ParameterValue
Mechanical durability (cycles)10000000 cycles
ZB4BW9337 — Mechanical
ParameterValue
Mounting diameter22 mm
ZB4BW9337 — Environmental
ParameterValue
IP protection ratingIP66 conforming to IEC 60529 IP67 IP69 IP69K
Operating temperature range-40...70 °C
Storage temperature range-40...70 °C
Vibration resistance5 gn (f= 2...500 Hz) conforming to IEC 60068-2-6
Shock resistance30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
ZB4BW9337 — Approvals & Standards
ParameterValue
Standards / approvalsJIS C8201-5-1 EN/IEC 60947-5-4 UL 508 EN/IEC 60947-5-5 EN/IEC 60947-1 CSA C22.2 No 14 EN/IEC 60947-5-1 JIS C8201-1
MPN
ZB4BW9337
