Schneider Electric ZB5AW37S — Emergency Stop Pushbuttons

Schneider Electric ZB5AW37S

MPNZB5AW37S
Obsolete

clear flush illuminated pushbutton head Ø22 spring return for BA9s bulb

Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

ZB5AW37S — Identification
ParameterValue
Product typeHead for illuminated push-button
Product rangeHarmony XB5
Device short nameZB5
Operator profileClear flush, unmarked
ZB5AW37S — Function & Operation
ParameterValue
Signaling head shapeRound
ZB5AW37S — Switching & Contacts
ParameterValue
Mechanical durability (cycles)10000000 cycles
ZB5AW37S — Mechanical
ParameterValue
Mounting diameter22 mm
ZB5AW37S — Environmental
ParameterValue
IP protection ratingIP66 conforming to IEC 60529 IP67 IP69 IP69K
Operating temperature range-40...55 °C
Storage temperature range-40...70 °C
Vibration resistance5 gn (f= 2...500 Hz) conforming to IEC 60068-2-6
Shock resistance30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
MPN
ZB5AW37S
