Siemens SIRIUS auxiliary contactor, 3RH1131-2AF00, size S00, 3 NO instantaneous contacts, screw and snap-on mounting, IP20 front protection.
| Parameter | Value |
|---|---|
| Contactor frame size | S00 |
| Parameter | Value |
|---|---|
| Rated operational current, AC-12, max. | 10 A |
| Rated value @ 400 V | 3 A |
| Rated value @ 500 V | 2 A |
| Rated value @ 690 V | 1 A |
| Rated value @ 230 V | 6 A |
| Rated value @ 24 V | 10 A |
| Rated value @ 110 V | 1 A |
| Rated value @ 220 V | 0.27 A |
| Parameter | Value |
|---|---|
| Control supply voltage type | AC |
| Rated value @ 50 Hz | 0.8 ... 1.1 |
| Rated value @ 50 Hz | 110 V |
| Parameter | Value |
|---|---|
| Auxiliary contact reliability | 1 faulty switching per 100 million (17 V, 1 mA) |
| Parameter | Value |
|---|---|
| Conductor cross-section, solid | 2x (0.25 ... 2.5 mm²) |
| Conductor cross-section, finely stranded w/ ferrule | 2x (0.25 ... 1.5 mm²) |
| Mounting method | screw and snap-on mounting |
| Parameter | Value |
|---|---|
| Durability (operating cycles, typ.) | 30 000 000 |
| Durability with aux. switch block (cycles, typ.) | 10 000 000 |
| Parameter | Value |
|---|---|
| Installation altitude, max. | 2 000 m |
| Parameter | Value |
|---|---|
| Width | 45 mm |
| Height | 60 mm |
| Depth | 73 mm |
It's the part you reach for when the main contactor's auxiliary block is full and you need extra NO contacts for a PLC input, a status lamp, or a permissive interlock.
At 24 V the contacts are rated 10 A — that's the full resistive load for a DC control circuit. At 230 V AC the rating drops to 6 A, and at 400 V AC it's 3 A. The 690 V rating of 1 A tells you this is a control-voltage contactor, not a power-switching device.
The 3RH2131-2AK60 is a peer in the same SIRIUS family with a similar contact configuration, but verify the coil voltage and terminal arrangement against your panel wiring before substituting — the 3RH1131-2AF00 uses screw and snap-on mounting with 2x (0.25...2.5 mm²) solid wire capacity, which may differ from the peer's termination.
Both are size S00 with the same 45 mm width and snap-on DIN rail mounting, so the footprint is identical. The terminal wiring capacity (2x 0.25...2.5 mm² solid) is also the same. The main difference is the contact arrangement — the 3RH1131-2AF00 has 3 NO + 0 NC, while the peer may carry a different NO/NC count. Check your schematic before swapping.
This part is sourced and quoted to order against an RFQ through independent distribution. Availability and current pricing are confirmed at quote time — submit an RFQ for a firm commitment.
