Siemens 5SY7310-7 — 3-Pole MCB (DIN Rail)

Siemens 5SY7310-7 SENTRON MCB, 3P C-Char, 15/30 kA

MPN5SY7310-7
Active

Siemens SENTRON 5SY7310-7, 3-pole miniature circuit breaker, C characteristic, 15 kA (EN 60898) / 30 kA (IEC 60947-2), 400 V AC, 3 MW units.

$46.99Ref. price · indicative, final on quote
Siemens 5SY7310-7 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

5SY7310-7 — Identification
ParameterValue
Brand nameSENTRON
Number of poles3
Pole configuration3P
Suitability for operationMechanical engineering / industry
5SY7310-7 — Protection
ParameterValue
Tripping characteristic (curve)C
Breaking capacity per EN 6089815 kA
Breaking capacity per IEC 60947-230 kA
Overvoltage categoryIII
IP protection classIP20, with connected conductors
Energy limitation class3
Pollution degree3
5SY7310-7 — Electrical
ParameterValue
Rated voltage (AC, multi-phase)440 V
Voltage type (AC/DC)AC
Supply frequency range50/60 Hz
Power loss per pole at rated current (AC, hot)1.1 W
Mechanical service life (operating cycles, typ.)10 000
Neutral conductor switchingNo
Rated voltage (AC, single-phase)440 V
5SY7310-7 — Mechanical
ParameterValue
Modular width units3
Mounting positionany
Width54 mm
Height90 mm
Depth76 mm
Installation depth70 mm
Terminal tightening torque, max.75 °C
Terminal tightening torque, min.-40 °C
Combined terminal, topYes
Combined terminal, bottomYes
Fastening methodQuick assembly system
SealableYes
Accepts supplementary devicesYes
5SY7310-7 — Environmental
ParameterValue
Halogen-freeYes
Silicone-freeYes
Influence of surrounding temperaturemax. 95% to 55°C, max. 55% to 70°C, max. 35% to 75°C
Vibration resistance (IEC 60068-2-6)±1mm at 5 to 25Hz; 50m/s² at 25 to 150Hz

Product details

It carries a 15 kA breaking capacity per IEC/EN 60898-1 and a 30 kA rating per IEC 60947-2, with a UL 1077 listing at 5 kA for North American installations. Rated for 400 V AC at 50/60 Hz, it occupies 3 modular width units (54 mm) on a DIN rail, with a depth of 76 mm and a quick-assembly fastening system.

Dual-rated under IEC/EN 60898-1 (15 kA) and IEC/EN 60947-2 (30 kA), with a UL 1077 listing at 5 kA for supplementary protection in North American panels. The sealable design and halogen/silicon-free construction support compliance documentation requirements for RoHS, REACH, and low-emission installations.

Snap-on DIN-rail mount, any position. Combined top and bottom terminals simplify busbar and cable routing. Neutral conductor is not switched — the 3-pole design handles line conductors only.

Frequently asked questions

Where can I buy 5SY7310-7 and how do I get a price?

This part is sourced and quoted to order against an RFQ through independent distribution. Availability and current pricing are confirmed at quote time — submit an RFQ for a firm commercial offer.

What compliance documentation does Siemens provide for 5SY7310-7?

The 5SY7310-7 carries IEC/EN 60898-1, IEC/EN 60947-2, and UL 1077 certifications. Its halogen-free and silicon-free construction supports RoHS and REACH compliance declarations. The sealable housing and pollution degree 3 rating are documented in the product specification.

What is 5SY7310-7's listed depth (76 mm) on this component line?

The overall depth is 76 mm, with an installation depth of 70 mm. The width is 54 mm (3 modular width units) and the height is 90 mm.
