Siemens 6ES7511-1FK02-0AB0 — PLCs (Programmable Logic Controllers)

Siemens 6ES7511-1FK02-0AB0 S7-1200 CPU, Failsafe, MRP

MPN6ES7511-1FK02-0AB0
Active

Siemens SIMATIC S7-1200 CPU 1211C, 6ES7511-1FK02-0AB0, failsafe-capable, MRP redundancy, 35×147×129 mm.

$698.50 – $1,838.83Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

6ES7511-1FK02-0AB0 — Processor & Memory
ParameterValue
Execution time, bit operations (typ.)60 ns
Execution time, word operations (typ.)72 ns
Execution time, floating-point arithmetic (typ.)384 ns
Size, max.16 kbyte
6ES7511-1FK02-0AB0 — I/O
ParameterValue
Input data area32 kbyte; All inputs are in the process image
Output data area32 kbyte; All outputs are in the process image
6ES7511-1FK02-0AB0 — Programming
ParameterValue
Programming language: FBDYes; incl. failsafe
Programming language: LADYes; incl. failsafe
Programming language: SCLYes
6ES7511-1FK02-0AB0 — Electrical
ParameterValue
Current consumption (rated)0.7 A
Permissible range, lower limit (DC)19.2 V
Permissible range, upper limit (DC)28.8 V
Power loss (typ.)5.7 W
6ES7511-1FK02-0AB0 — Environmental
ParameterValue
Installation altitude, max.5 000 m; Restrictions for installation altitudes > 2 000 m, see manual
Temperature, min.-40 °C
Temperature, max.70 °C
Operating temperature, min. (horizontal mounting)-25 °C; No condensation
Operating temperature, max. (horizontal mounting)60 °C; Display: 50 °C, at an operating temperature of typically 50 °C, the display is switched off
6ES7511-1FK02-0AB0 — Mechanical
ParameterValue
Width35 mm
Height147 mm
Depth129 mm
Weight (approx.)405 g

Product details

The 6ES7511-1FK02-0AB0: This Siemens CPU 1211C packs failsafe FBD programming and PROFIsafe into a 35 mm wide brick — no separate safety PLC needed for SIL-rated lines. It runs MRP as redundancy manager (up to 50 devices in the ring), so you can loop PROFINET without an extra switch module. The 32 kB I/O image handles a couple of remote racks, and the -40 to 70 °C range means it won't flake in an unheated warehouse. Firmware revision -FK02 is the current drop; the -FK01 predecessor shares the same mechanical footprint but lacks some software optimizations.

Field-fit notes

DIN-rail mount, 35 mm wide, 147 mm tall, 129 mm deep. DCP enables device configuration; FBD with failsafe allows safety logic; forcing limited to non-fail-safe signals. I/O mapping is straightforward: 32 kB input and output process images. All four CM/CP slots populate via the side bus; max four comm modules total (PROFIBUS, PROFINET, Ethernet). For MODBUS TCP, it's built-in — no extra card needed.

Frequently asked questions

Does the 6ES7511-1FK02-0AB0 support MRP as manager?

Yes, it supports MRP as redundancy manager and/or client, up to 50 devices in the ring. This lets it manage ring redundancy without a separate switch.

Can I replace a 6ES7511-1FK01-0AB0 with this -FK02 version without rewiring?

Yes, the mechanical dimensions and connector layout are identical. The -FK02 will drop into the same panel without rewiring, but verify the TIA Portal version supports the newer firmware.

What does 'FBD incl. failsafe' mean for this CPU?

It means the CPU can execute safety logic written in Function Block Diagram and ladder, including failsafe (SIL) functions, without an additional safety PLC. This integrates safety and standard control in one unit.

What is the operating temperature range?

Rated for -40 °C to 70 °C ambient, suitable for unheated environments or enclosures without cooling.
