Schneider Electric ABL4WSR24200
MPNABL4WSR24200
Obsolete
Regulated Switch Power Supply, 3 phase, 400..500V AC, 24V, 20A
$379.59Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
| Parameter | Value |
|---|---|
| Range of product | Modicon Power Supply |
| Power supply type | Regulated switch mode |
| Output protection type | Against short-circuits, protection technology: automatic reset Against overload, protection technology: 33 V Thermal Against overvoltage |
| Product or component type | Power supply |
| Output voltage | 24 V DC |
| Nominal input voltage | 400...500 V AC three phase, terminal(s): L1, L2, L3 |
| Output voltage adjustment | 100...116 % adjustable |
| Inrush current | 10 A |
| Current consumption | 1.1 A 500 V AC 1.3 A 400 V AC |
| Power supply output current | 20 A |
| Permissible temporary current boost | 1.5 x In (for 5 seconds) |
| Power factor | 0.75 at 24 V DC |
All specifications+16 ▾
| Parameter | Value |
|---|---|
| Rated power in | 480 W |
| Power dissipation in | 30 W 36 W |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Mounting support | 35 x 15 mm symmetrical DIN rail 35 x 7.5 mm symmetrical DIN rail |
| Connections - terminals | Screw type terminals: 2 x 0.5...2 x 4 mm², (AWG 24...AWG 10) for input connection Screw type terminals: 1 x 0.5...1 x 4 mm², (AWG 24...AWG 10) for input ground connection Screw type terminals: 2 x 0.5...2 x 4 mm², (AWG 24...AWG 10) for output connection Screw type terminals: 2 x 0.5...2 x 4 mm², (AWG 24...AWG 10) for diagnostic relay |
| Depth | 139 mm |
| Width | 80 mm |
| Height | 127 mm |
| Standards | CULus 508 EN/IEC 62368-1 |
| Supply | SELV conforming to IEC 60950-1 SELV conforming to IEC 60204-1 SELV conforming to IEC 60364-4-41 |
| Marking | CE |
| Efficiency | 93 % at 400 V AC 94 % at 500 V AC |
| Status LED | 1 LED (green) output voltage (> 21.6 V) 1 LED (red) overload, overtemperature, overvoltage |
| Output coupling | Series Parallel |
| Operating position | Vertical |
| Environmental characteristic | EMC conforming to EN 50081-1 EMC conforming to EN 50082-2 EMC conforming to IEC 61000-6-2 Safety conforming to EN/IEC 60950 |
MPN
ABL4WSR24200
