Schneider Electric C11H34V050B — Residual Current Breakers (RCCB/RCBO)

Schneider Electric C11H34V050B ComPacT NSXm MCCB, 50 A, 70 k

MPNC11H34V050B
Active

Schneider Electric ComPacT NSXm, C11H34V050B, 3-pole MCCB, 50 A at 40 °C, 70 kA at 415 V AC, MicroLogic 4.1 electronic trip unit, integrated earth-leakage.

Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

C11H34V050B — Residual Current Protection
ParameterValue
Earth-leakage sensitivity (IΔn)30 mA for class A 100 mA for class A 300 mA for class A 500 mA for class A 1 A for class A 30 mA for class AC 100 mA for class AC 300 mA for class AC 500 mA for class AC 1 A for class AC 3 A for class AC 5 A for class AC
Earth-leakage protection class / typeClass A Class AC
Trip unit technologyElectronic
Local signalling / indicationFlag (green) for presence of auxiliary contacts
C11H34V050B — Electrical Ratings
ParameterValue
Rated current (In)50 A at 40 °C
Rated operational voltage (Ue)440 V AC 50/60 Hz
Poles description3P
Network typeAC
Network frequency50/60 Hz
Rated insulation voltage (Ui)500 V AC 50/60 Hz
Rated impulse withstand voltage (Uimp)8 kV
Overvoltage categoryIV
Electrical durability20000 cycles at 440 V In/2 10000 cycles at 440 V In
Mechanical durability (operating cycles)20000 cycles
C11H34V050B — Identification
ParameterValue
Product nameComPacT NSXm
Product / component typeEarth leakage circuit breaker
Product range / familyComPacT
Device short nameNSXm 63H
C11H34V050B — Mechanical
ParameterValue
Mounting supportBackplate
Mounting positionHorizontal and vertical Flat on the back
Control typeToggle
Width in 9 mm modules9 module
C11H34V050B — Environmental
ParameterValue
Operating ambient temperature-25...70 °C
Storage ambient temperature-40...85 °C
IP degree of protectionIP40 conforming to IEC 60529
Pollution degree3 conforming to IEC 60664-1
Relative humidity0...95 %
Operating altitude2000 m without derating 5000 m with derating
C11H34V050B — Approvals
ParameterValue
StandardsEN/IEC 60947-2

Product details

The Schneider Electric C11H34V050B is a ComPacT NSXm moulded-case circuit breaker with 3 poles, rated 50 A at 40 °C and a 70 kA interrupting capacity at 415 V AC — the H performance level. It carries a MicroLogic 4.1 electronic trip unit with integrated earth-leakage protection, adjustable from 30 mA to 5 A in class A or AC sensitivity. Built to EN/IEC 60947-2, it is a distribution-grade MCCB for panelboards, switchboards, and sub-distribution in commercial or light industrial sites.

The MicroLogic 4.1 is a fixed-curve electronic trip unit — no field-adjustable long-time or short-time pickup, but it includes thermal memory that remembers the last 20 minutes of heating before and after a trip, preventing nuisance reclosure on a hot cable. Integrated earth-leakage protection means this single device covers both overcurrent and ground-fault in one package — no separate RCCB or RCBO needed. Sensitivity choices cover 30 mA (personnel protection) up to 5 A (equipment protection), selectable by the installer.

Mounting and integration notes

Mounts on a backplate in horizontal or vertical orientation — flat on the back. The 9-module pitch (108 mm wide, 144 mm high, 80 mm deep) fits standard 35 mm DIN-rail enclosures with spreaders; without spreaders the connection pitch is 27 mm. Front connections top and bottom accept compression lugs or busbars. IP40 front face, IK07 impact resistance — suitable for enclosed panel installation, not for washdown areas.

Frequently asked questions

Where can I buy C11H34V050B and what is the lead time?

This part is sourced to order against an RFQ through independent distribution. Availability and current pricing are confirmed at quote time — no stock or lead-time figures are published here.

What is the closest alternative to C11H34V050B in the same family?

Within the ComPacT NSXm range, the closest peer would share the same frame (NSXm 63H) and pole count but differ in trip unit rating or earth-leakage sensitivity. No pin-compatible direct substitute is listed; the exact order code should be matched for a BOM line.

What compliance documentation does Schneider provide for C11H34V050B?

The breaker is certified to EN/IEC 60947-2. The manufacturer typically provides a Declaration of Conformity covering the applicable EU directives; specific RoHS, REACH, and UL documentation should be requested at quote time.
