LV426117
Schneider Electric
4PE 16 kA 415 V ACDistribution Protection
Ref. price$147.61
Lead time on requestGet quote
Schneider Electric LV426 Molded Case Breakers Series
359 variants · Schneider Electric
About the Schneider Electric LV426 Molded Case Breakers Series
The Schneider Electric LV426 Molded Case Breakers Series series groups 359 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common color of Grey (RAL 7016), control type of Toggle and depth of 80 mm. Variants differ by application, poles and width, so you can match the exact application your application requires using the selection guide below.
Select a variant by
- Application
- Distribution Protection · Protection Distribution
- Poles
- 3P · 4P
- Width
- 81 mm · 108 mm
Shared specifications
- Color
- Grey (RAL 7016)
- Control type
- Toggle
- Depth
- 80 mm
- Electrical life cycles
- 10000 cycles at 440 V In 20000 cycles at 440 V In/2 5000 cycles at 690 V In 10000 cycles at 690 V In/2
- Height
- 137 mm
- IP rating
- IP40
- Main product or component type
- Circuit breaker
- Mechanical life cycles
- 20000 cycles
- Operating temperature
- -25...70 °C
- Pollution degree
- class 3
- Safety category
- E 16 kA 415 V AC
- Storage temperature
- -50...85 °C
Variant comparison
| Parameter | LV426113 | LV426115 | LV426117 | LV426119 | LV426121 | LV426123 |
|---|---|---|---|---|---|---|
| Application | Protection Distribution | Protection Distribution | Distribution Protection | Protection Distribution | Protection Distribution | Protection Distribution |
| Poles | 4P | 4P | 4P | 4P | 4P | 4P |
| Width | 108 mm | 108 mm | 108 mm | 108 mm | 108 mm | 108 mm |
Request a quote on any Schneider Electric LV426 Molded Case Breakers Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
