XS530B1PAL2
Schneider Electric
IP68 / IP69K24–48 VXS5
Ref. price$17.78
Lead time on requestGet quote
Schneider Electric XS530B1 Series
19 variants · Schneider Electric
About the Schneider Electric XS530B1 Series
The Schneider Electric XS530B1 Series series groups 19 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by IP rating, supply voltage and output circuit type, so you can match the exact IP rating your application requires using the selection guide below.
Select a variant by
- IP rating
- IP67 / IP69K · IP68 / IP69K
- Supply voltage
- 24-240 V AC ; 24-240 V DC · Not Rated ; 12-24 V DC · Not Rated ; 12-48 V DC
- Output circuit type
- AC/DC-Type · DC · NPN · PNP
- Frequency
- 1000 HZ · 1000 Hz
- Voltage
- 12 TO 24 VDC · 12 to 24 VDC
Variant comparison
| Parameter | XS530B1PAL2 | XS530B1PBL2 | XS530B1MAL2 | XS530B1NAM12 | XS530B1DAL2 | XS530B1NAL2 |
|---|---|---|---|---|---|---|
| IP rating | IP68 / IP69K | — | IP68 / IP69K | IP67 / IP69K | IP68 / IP69K | IP68 / IP69K |
| Supply voltage | Not Rated ; 12-24 V DC | — | 24-240 V AC ; 24-240 V DC | Not Rated ; 12-24 V DC | Not Rated ; 12-48 V DC | Not Rated ; 12-24 V DC |
| Output circuit type | PNP | — | AC/DC-Type | NPN | DC | NPN |
| Frequency | — | 1000 HZ | — | — | — | — |
| Voltage | — | 12 TO 24 VDC | — | — | — | — |
Request a quote on any Schneider Electric XS530B1 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
