SIPLUS LOGO! 24CEO with conformal coating
The Siemens 6AG1052-2CC08-7BA0 is a SIPLUS variant of the standard LOGO! 24CEO logic module (6ED1052-2CC08-0BA0), distinguished by a conformal coating that qualifies it for environments with condensation, coolant mist, and airborne oil or diesel droplets. It carries 8 digital inputs, 4 of which can be configured as analog inputs (0 to 10 V), and 4 transistor digital outputs with electronic short-circuit protection at 1 A.
Extended temperature and environmental resilience
The conformal coating and resistance to coolants, lubricants, diesel, and oil droplets make this module suitable for harsh industrial environments. Radio interference suppression meets EN 55011 Limit Class B, so the module can be used in residential areas without additional filtering.
Memory, power backup, and network integration
Program memory supports up to 400 function blocks, and the integrated power reserve holds the real-time clock and retentive data for up to 480 hours without external supply. An Ethernet port provides integrated web server, data logging, and user-defined web pages. The module accepts a standard microSD card for program storage and is programmable with LOGO! Soft Comfort V8 or higher. Supply voltage range is 20.4 V to 28.8 V DC.
Active production and ordering
It is a direct SIPLUS derivative of the standard LOGO! 24CEO (6ED1052-2CC08-0BA0), adding conformal coating and extended temperature range. Existing projects from the standard module can be reused without modification.
