XS7C2A1PAM12
Schneider Electric
< 40 Hz40 MM W X 40 MM D X 70 MM H8–20 mm
Ref. price$22.86
Lead time on requestGet quote
Schneider Electric XS7C Series
34 variants · Schneider Electric
About the Schneider Electric XS7C Series
The Schneider Electric XS7C Series series groups 34 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by sensing distance, temp operating max and temp operating min, so you can match the exact sensing distance your application requires using the selection guide below.
Select a variant by
- Sensing distance
- > 0.31...0.59 IN (> 8...15 MM) · 15 MM
- Temp operating max
- -25 °C · 158 °C
- Temp operating min
- -70 °C · -13 °C
- Dimensions
- 40 MM W X 15 MM D X 40 MM H · 40 MM W X 15 MM D X 54 MM H · 40 MM W X 40 MM D X 70 MM H
- Frequency
- 25 HZ (AC), 300 HZ (DC) · 1000 HZ
- Sensing position
- 5 POSITION · Front
- Supply voltage
- 12...24 V DC REVERSE POLARITY PROTECTION · 24-240 V AC ; 24-240 V DC · Not Rated ; 12-48 V DC
- Output circuit type
- AC/DC-Type · Programmable
Variant comparison
| Parameter | XS7C2A1PAM12 | XS7C2A1NBM12 | XS7C4A1MPN12 | XS7C4A1MPG13 | XS7C4A1DPG13 | XS7C2A1MAU20 |
|---|---|---|---|---|---|---|
| Sensing distance | 15 MM | 15 MM | — | — | — | — |
| Temp operating max | 158 °C | 158 °C | — | — | — | — |
| Temp operating min | -13 °C | -13 °C | — | — | — | — |
| Dimensions | 40 MM W X 40 MM D X 70 MM H | 40 MM W X 40 MM D X 70 MM H | — | — | — | — |
| Frequency | 25 HZ (AC), 300 HZ (DC) | 25 HZ (AC), 300 HZ (DC) | — | — | — | — |
| Sensing position | 5 POSITION | 5 POSITION | — | — | — | — |
| Supply voltage | — | — | 24-240 V AC ; 24-240 V DC | 24-240 V AC ; 24-240 V DC | Not Rated ; 12-48 V DC | 24-240 V AC ; 24-240 V DC |
| Output circuit type | — | — | Programmable | Programmable | Programmable | AC/DC-Type |
Request a quote on any Schneider Electric XS7C Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
