XS8C1A1NAL01M12
Schneider Electric
24–48 V≥ 1000 Hz40 MM W X 15 MM D X 54 MM H
Ref. price$162.00 – $396.00
Lead time on requestGet quote
Schneider Electric XS8C Series
32 variants · Schneider Electric
About the Schneider Electric XS8C Series
The Schneider Electric XS8C Series series groups 32 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by dimensions, IP rating and output circuit type, so you can match the exact dimensions your application requires using the selection guide below.
Select a variant by
- Dimensions
- 40 MM W X 15 MM D X 51 MM H · 40 MM W X 15 MM D X 54 MM H
- IP rating
- IP65 / IP67 / IP69K · IP67 · IP68
- Output circuit type
- AC/DC-Type · NPN · PNP
- Supply voltage
- 24-240 V AC ; 24-240 V DC · Not Rated ; 12-48 V DC
- Voltage
- 12 TO 24 VDC · 24 TO 240 VAC, 24 TO 210 VDC
- Pin count
- 3 · 4
Variant comparison
| Parameter | XS8C1A1NAL01M12 | XS8C1A1MBL01U20 | XS8C1A1MBL2 | XS8C1A1MAL01U20 | XS8C1A1MAL2 | XS8C1A1PAM8 |
|---|---|---|---|---|---|---|
| Dimensions | 40 MM W X 15 MM D X 54 MM H | 40 MM W X 15 MM D X 54 MM H | 40 MM W X 15 MM D X 54 MM H | — | — | 40 MM W X 15 MM D X 51 MM H |
| IP rating | — | — | — | IP67 | IP68 | — |
| Output circuit type | — | — | — | AC/DC-Type | AC/DC-Type | — |
| Supply voltage | — | — | — | 24-240 V AC ; 24-240 V DC | 24-240 V AC ; 24-240 V DC | — |
| Voltage | 12 TO 24 VDC | 24 TO 240 VAC, 24 TO 210 VDC | 24 TO 240 VAC, 24 TO 210 VDC | — | — | 12 TO 24 VDC |
| Pin count | — | — | — | 3 | — | — |
Request a quote on any Schneider Electric XS8C Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
