Omron S8VK Din Rail Power Supplies Series

32 variants · OmronAll DIN Rail Power Supplies →

About the Omron S8VK Din Rail Power Supplies Series

The Omron S8VK Din Rail Power Supplies Series series groups 32 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by depth, efficiency and height, so you can match the exact depth your application requires using the selection guide below.

Select a variant by

Depth: 90 mm · 122.2 mm · 180 mm
Efficiency: 86% · 89% · 92%
Height: 90 mm · 125 mm
Insulation voltage ui: 3 kV · 3000 V
Output current: 10 A · 20 A · 40 A · 48 A
Output power: 480 W · 960 W
Power: 30 W · 120 W · 960 W
Ripple noise: 90 mV · 160 mV · 190 mV

Variant comparison

Parameter	S8VKT12024	S8VK-T96024-400	S8VKS03024	S8VKT96024400	S8VKT12024400	S8VK-G48048-400
Depth	122.2 mm	—	90 mm	180 mm	122.2 mm	—
Efficiency	89%	—	86%	92%	89%	—
Height	125 mm	—	90 mm	125 mm	125 mm	—
Insulation voltage ui	3 kV	—	3 kV	3000 V	3 kV	—
Output current	—	40 A	—	48 A	—	10 A
Output power	—	960 W	—	960 W	—	480 W
Power	120 W	—	30 W	960 W	120 W	—
Ripple noise	160 mV	—	190 mV	90 mV	160 mV	—

Request a quote on any Omron S8VK Din Rail Power Supplies Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
